Roadvision Stealth S40 13" LED Light Bar

Roadvision Stealth S40 13-inch Slimline LED Light Bar

Product Overview:

When you are navigating dark country roads or pushing deep into the outback after sunset, you need lighting that punches well above its weight. The Roadvision Stealth S40 13-Inch LED Light Bar delivers exactly that, combining cutting-edge Projector Beam Technology with a highly compact, slimline footprint. Striking the perfect balance between long-range performance and aggressive styling, this 13-inch powerhouse pushes out 3218 maximum lumens, throwing a brilliant white beam up to a staggering 416 metres at 1 Lux. What truly sets the Stealth series apart is its aggressive aesthetic, featuring a smoked-look polycarbonate lens and blackout mounting hardware, it provides a sleek, low-profile look that blends seamlessly into your 4WD’s bull bar or roof rack.

Built tough to conquer the harsh Australian environment, the S40 series is encased in a lightweight, rugged die-cast aluminium housing that is fully IP67 water and dust proof. Backed by Roadvision’s best-in-class Platinum Range 7-year warranty, this light bar is engineered for ultimate uncompromised reliability. Equipped with Advanced Thermal Management Technology to prevent overheating and a 9-position anti-vibration mounting system, it effortlessly handles corrugated dirt roads, deep river crossings, and sweltering summer nights. It is the ultimate combination of high-end performance, outback-ready durability, and modern stealth styling.

Roadvision Stealth S40 Features & Benefits

• Next-Gen Projector Beam Technology: Utilises advanced projector lenses to squeeze maximum power and a highly focused, long-range beam out of a highly compact 13-inch package.
• Aggressive Stealth Aesthetics: The unique smoked-look lens and completely blacked-out mounting hardware give your rig a clean, modern, and stealthy factory-finish appearance.
• Intense Osram Illumination: Driven by 12 premium 3W Osram LEDs, producing a super crisp white light that closely mimics daylight, drastically reducing eye fatigue on long night drives.
• Advanced Thermal Management: Smart built-in technology continuously monitors and adjusts output based on environmental temperatures, preventing the unit from overheating and extending the lifespan to an incredible 50,000 hours.
• Outback-Ready Durability: Proudly holding an IP67 rating, the tough die-cast aluminium housing and unbreakable polycarbonate lens are fully sealed against fine bulldust and torrential rain.
• Versatile & Secure Fitment: Includes a 9-position adjustable anti-vibration end mount system as well as low-profile slide mounts, offering total flexibility when attaching to nudgebars, bull bars, or racks.
• No Radio Interference: Fully EMI/EMC approved, ensuring this high-output light bar won't cause static or radio frequency interference on your UHF or AM/FM channels.

Roadvision Stealth S40 Technical Specifications

Specification	Details
Brand	Roadvision
Series	Stealth S40 (Slimline Long Range)
Beam Type	Projector Beam
Maximum Lumens	3218lm
Light Source	12 x 3W Osram LEDs
Voltage Input	10-30V DC
Maximum Watts	49W
Current Draw	2.9 - 4.1 Amps @ 13.8V
Meters @ 1 Lux	416 Metres
Maximum Beam Distance	832 Metres (@ 0.5 Lux)
Ingress Protection	IP67 (Water & Dust Proof)
Dimensions (W x D x H)	315mm x 55mm x 40mm
Wiring	2-Pin Deutsch Plug



Frequently Asked Questions

1. Is this light bar suitable for a 12V 4WD and a 24V truck? Absolutely. Featuring a multi-volt 10-30V DC input range, the S40 light bar is fully compatible with standard 12-volt passenger and recreational vehicles, as well as 24-volt commercial and agricultural machinery.

2. What mounting options come with the 13" S40 light bar? The unit provides excellent flexibility, coming standard with both a 9-position adjustable anti-vibration end mount system and low-profile slide mounts, making it easy to fit to various bull bars, nudge bars, and roof racks.

3. Will the S40 series interfere with my UHF radio? No. Roadvision's Stealth series is fully EMI and EMC approved. The internal electronics are heavily shielded to ensure they do not cause any static or radio frequency interference with your vital communication equipment.

4. Can this light bar survive deep river crossings? Yes. The Stealth S40 boasts a stringent IP67 water and dust proof rating. It is completely sealed against bulldust ingress and can easily withstand deep water crossings and heavy coastal rain.

5. How does the "Thermal Management Technology" work? High-output LEDs naturally generate heat. This smart technology monitors the internal temperature of the light bar and automatically adjusts the power output to prevent overheating, especially on hot, still summer nights, thereby protecting the circuitry and ensuring a 50,000-hour lifespan.

6. Does it come with a wiring harness? The light bar is equipped with a high-quality, waterproof 2-pin Deutsch plug for a secure connection. However, a complete wiring harness (with relay and switch) is typically sold separately depending on your specific vehicle setup.
