Roadvision BR390ARR LED Rear Combination Lamp 10-30V

Roadvision LED Rear Combination Lamp 10-30V Stop/Tail/Ind/Ref Glowtech Tail 390x105x39mm

Product Overview:

Elevate your 4WD tray, caravan, or heavy-duty commercial trailer with the Roadvision BR390 Series LED Combination Lamp. Striking the perfect balance between cutting-edge automotive styling and uncompromising outback performance, this premium 390mm unit features a striking Grey Glowtech tail light and a sweeping sequential indicator. Finished with a mild tinted lens and a sleek gun metal grey chrome bezel, it delivers a high-end, modern aesthetic while vastly improving your road presence and safety in dusty, low-visibility conditions across the Australian highway network.

Built incredibly tough for work and play, the BR390 Series is specifically engineered to survive the relentless vibrations, flying gravel, and harsh UV rays of the harsh Aussie environment. It seamlessly combines Stop, Tail, and Indicator functions with a highly visible integrated Retro Reflector into one durable, lightweight polycarbonate housing. Boasting a massive 100,000-hour solid-state LED lifespan and a versatile 10-30V DC input, this fully ADR-approved surface mount lamp is the ultimate "Fit and Forget" upgrade for your 12V ute or 24V transport rig.

Roadvision BR390 Features & Benefits

• Dynamic Glowtech & Sequential Signals: The cutting-edge Grey Glowtech tail light and progressive sequential indicators provide a premium, modern look while making your turning intentions unmistakable to following drivers.
• All-in-One Functionality: Combines Stop, Tail, and Indicator functions with a built-in Retro Reflector, keeping your vehicle safely illuminated and fully road legal without cluttering your tray with separate lighting modules.
• Multi-Voltage 10-30V Input: Operates seamlessly across standard 12V passenger and recreational vehicles as well as 24V heavy commercial trucks, offering true plug-and-play versatility for any fleet.
• Ultra-Low Power Draw: The highly efficient solid-state LED configuration draws a fraction of the current of traditional incandescent bulbs, preserving your vital battery reserves while off-grid.
• Outback-Ready Durability: Constructed with a lightweight, virtually unbreakable polycarbonate housing and lens, it effortlessly absorbs the heavy vibrations and physical impacts common on severely corrugated dirt roads.
• Striking Stealth Aesthetics: Features a mild tinted lens paired with a sophisticated gun metal grey chrome finish, adding a sleek styling upgrade to your vehicle.
• Simple Surface Mount: Designed for quick, hassle-free installation on flat surfaces, allowing you to easily upgrade your lighting setup with basic hand tools.

Roadvision BR390 Technical Specifications

Specification	Details
Brand	Roadvision
Series	BR390 Series
Lamp Functions	Stop / Tail / Sequential Indicator / Reflector
Voltage Input	10-30V DC
LED Configuration	Ind: 15 / Stop: 60 / Tail: 54 LEDs
Current Draw (@ 13.8V)	Ind: 0.57A / Stop: 0.29A / Tail: 0.18A
Lens & Housing Material	High-Impact Polycarbonate (Mild Tinted Lens)
Finish	Gun Metal Grey Chrome
Overall Dimensions	390mm x 105mm x 39mm
Mounting Style	Simple Surface Mount
Wiring Connection	Earth (White), Stop (Red), Tail (Brown), Ind (Yellow)
Compliance	Full ADR Approved for all functions



Frequently Asked Questions

1. What is the "Grey Glowtech" tail light feature? The Glowtech feature provides a smooth, continuous band of illumination rather than individual visible LED dots. It adds a modern, high-end automotive styling touch to your vehicle, standing out sharply and distinctly against standard static tail lights.

2. Is this combination lamp suitable for both 12V and 24V vehicles? Absolutely. Thanks to its multi-volt 10-30V DC input circuitry, the BR390 is fully compatible with 12V utes, 4WDs, and camper trailers, as well as 24V commercial trucks and agricultural machinery.

3. Does this specific model include a reverse light? No, this specific BR390 model is dedicated to Stop, Tail, Indicator, and Reflector functions. It is perfect for vehicle setups that already feature an independent reverse light.

4. How is the BR390 light mounted to my vehicle? The lamp features a simple surface mount design. This means it can be easily bolted directly onto any flat surface on your tray, canopy, or rear bar without the need to cut massive recessed holes into your bodywork.

5. How do I wire this light to my vehicle? The unit uses standard colour coding for a straightforward installation: White for Earth, Red for Stop, Brown for Tail, and Yellow for the Indicator.

6. Will this light withstand heavy corrugations and flying gravel? Yes. Both the housing and the lens are constructed from highly durable, impact-resistant polycarbonate. It is specifically designed to absorb the heavy vibrations and physical impacts experienced on harsh Australian outback tracks.

7. Do the internal LED bulbs ever need replacing? No. This lamp utilises solid-state LED technology rated for an incredible 100,000 hours of use. It is a completely maintenance-free, sealed unit designed to easily outlast the vehicle it is mounted to.
