Reyee RG-EST350 V2 5GHz PTP Wireless Bridge Pre-Paired

PRODUCT DETAILS

Ruijie Reyee RG-EST350 (V2) 5GHz 15dBi Point-to-Point Wireless Bridge (Pre-Paired Pack)

The Ruijie Reyee RG-EST350 (V2) is designed to effortlessly transmit data over distances of up to 5 km in real time. This high-performance wireless bridge utilises advanced Wi-Fi 5 technology (IEEE 802.11ac, Wave2) to deliver reliable connectivity, making it an ideal solution for various applications, including remote surveillance and data transfer.

Key Features:

• Capable of transmitting data from up to 5 km away in real time
• Factory-paired bridges for easy long-distance installation
• IP54 weatherproof rating
• Monitoring available via Ruijie cloud
• Wi-Fi 5 (IEEE 802.11ac, Wave2)
• Dual-stream technology
• 2×2 MIMO and MU-MIMO support
• 15 dBi directional antenna gain
• 2x 10/100/1000 Base-T fixed ports
• Adjustable transmit power of ≤400 mW (26 dBm)

SPECIFICATIONS

Category	Specification	Details
Model	RG-EST350 (V2)	5GHz Point-to-Point Wireless Bridge
Wi-Fi Standards	IEEE 802.11ac (Wave 2)	Wi-Fi 5 support
MIMO	2X2, MU-MIMO	Improved data transmission
Max. Wireless Speed	5 GHz	867 Mbps
Antenna Gain	15 dBi	Directional antenna for long range
Weatherproof Rating	IP54	Durable in harsh conditions
Polarisation	Optimised signal reception	Horizontal: 31° Vertical: 14°
Operating Temperature	-30 °C to 65 °C
Recommended Distance	5 KM
Fixed Ports	2 x 10/100/1000 Base-T	Gigabit Ethernet connectivity
Transmit Power	≤400 mW (26 dBm) (adjustable)	Customisable power output
Dimensions	230 mm x 132 mm x 48 mm
Weight	0.5 kg
Certification	Types	CE RoHS
